Elite+ EI2 60/120

The metallic door Elite+ combines perfectly functionality and aesthetics.
Several possible solutions: painted in colours Ral, decorative printing NovoPrint, stainless steel, fixing on plasterboard wall.

TECHNICAL FEATURES:

Frame in galvanized steel Z shape mm. 15/10, without bottom profile, prepared for installation of cold smoke seal.
Leaf in galvanized steel mm. 8/10, total thickness mm. 64. High density package inside.
Standard equipment: two adjustable hinges, couple of black handles with plate, cylinder with three keys, lock on both leaves, arm closing selector, thermo.
expanding gasket on the perimeter.
Possible installation of bottom mobile threshold, panic devices, electromagnets and door closers.
Maximum size possible mm. 2670x2640h.

STANDARD EQUIPMENT

Security Bolts

Standard equipment: no. 2 anchor shaped security bolts with security burglar-function.

Front Plate

Adjustable nickel plate for the latch. Higher durability of the frame's painting.

Painting in Ral colors

Wide range of finishing: in addition to the traditional RAL powder coating, you can choose one of our Novoprint decorative painting

Hinges

Realized in Galvanized steel , inside spring for automatic leaf closing.
Fixed on frame and leaf with adjustable screw.
Painted in Ral color.

Door cordinator device

Standard equipment on two-leaves doors, black colour ( other finishing are available on request).
The device is fixed with screws on the horizontal profile of the frame.

MANY CUSTOMIZATIONS AND ACCESSORIES

... With different materials

Standard

Galvanized steel 8/10

On request

Galvanised steel 10/10
Galvanised steel 12/10
Galvanised steel 15/10
Stainless steel

... With many colors

STANDARD COLORS

Oyster white,
RAL 1013

Pure white,
RAL 9010

Gentian blue,
RAL 5010

Traffic white,
RAL 9016

Light grey,
RAL 7035

Anthracite grey,
RAL 7016

Grey white,
RAL 9002

White aluminium,
RAL 9006

COLORS AT AN ADDITIONAL PRICE

Beige,
RAL 1001

Blue grey,
RAL 7031

Ruby red,
RAL 3003

Grey brown,
RAL 8019

Sky blue,
RAL 5015

Cream,
RAL 9001

Pastel blue,
RAL 5024

Jet black,
RAL 9005

Mass green,
RAL 6005

RAL colors
of your choice

Silver grey,
RAL 7001

RAL out of production, not available:
RAL 1003, 1014, 1021, 2011, 6011, 6018, 6027, 6028, 6033

Would you like anything else?
The door is available with an extra charge, in any RAL color. Your dealer will help you choose the right color for your door.

... WITH MANY GLAZED WINDOWS

Rectangular and circular glazed Windows are inserted on request.

The glasses are tested to be ﬁre proof, composed by multiple stratum of ﬂoat glass and special transparent gel which, develops an opaque insulating foam in case of ﬁre.
Glasses are ﬁxed by metal proﬁles clipped on hidden screws and rubber gasket which protects the movement of glazing because of hight temperature rise.
Available standard and special sizes of glazing.

Circular glazed windows

Standard dimensions:

400 mm.

Rectangular Glazed Windows

Standard dimensions:

300x400 mm.
400x600 mm.

NOTES

In case of frequent usage and glass bigger than mm. 300*400, it is advisable to mount a door closer.
The glass is pre-mounted on the door leaf.
Fire glass deteriorates in color if exposed to direct sunlight or in contact with water.
Fire rated Glass could have micro bubbles and when not visible at distance of more than 3 meters it is within our norms.

... Different performance

EI2 60/120

FIRE RESISTANCE UP TO 120 MINUTI

Smoke Control class Sa / Sm

SMOKE CONTROL CLASS SA / SM

Sound insulation up to 39dB

SOUND INSULATION UP TO 39DB (WITH SEALING OF EACH INTERSTICE BETWEEN MASONRY AND FRAME)

Air permeability up to Class 3

AIR PERMEABILITY UP TO CLASS 3 WITH EXT3 KIT

Wind load resistance up to class C3

WIND LOAD RESISTANCE UP TO CLASS C3 WITH EXT 3 KIT

Water tightness up to class 2B

WATER TIGHTNESS UP TO CLASS 2B WITH EXT3 KIT

Termal transmittance up to 1,8W/m²K

TERMAL TRANSMITTANCE UP TO 1,8W/M²K

...2 Types of Wrap-around frame

Wrap-around frame, external mounted

Wrap-around frame, internal mounted

Supply according to customer's request.

Wrap-around frame made of galvanized steel with thickness:

8/10 for external mounted
10/10 for internal mounted

Painted in RAL.

... 5 FIXING SYSTEMS

Le porte Elite+ sono testate su supporto flessibile normalizzato, secondo la norma EN 1363-1, punto 7.2.2. In ottemperanza a quanto riportato al punto 13.5.3. della EN 1634-1 si ha quindi la possibilità di installare il prodotto su ogni costruzione flessibile non normalizzata, che abbia resistenza al fuoco almeno pari alla resistenza del serramento.
